Recycling Li-Ion Batteries

Sure, the electric vehicle market is growing. But there’s the non-trivial issue of critical materials for the batteries for all of those new cars, trucks and SUVs. . .

By Gary S. Vasilash

Ajay Kochhar, CEO and co-founder of Li-Cycle, points out something that should give everyone a bit of pause when it comes to the burgeoning electric vehicle market: In 2013 there were three electric vehicle battery plants. In 2021 there are 225 existing on the way.

According to the Critical Materials Institute, which is under the U.S. Dept. of Energy, the definition of critical material is: “Any substance used in technology that is subject to supply risks, and for which there are no easy substitutes.”

Things like lithium used in batteries. Or nickel. Or cobalt.

Lots of battery plants. Not a whole lot of readily available—to say nothing of environmentally available (mining is not necessarily conducted in places where there is more concern with getting the stuff out of the ground than how that ground will be after the important stuff is removed in an environmentally benign manner)—critical materials.

Kochhar and his colleague Tim Johnson once worked on the lithium-extraction part of the business, Kochhar says on this edition of “Autoline After Hours.” He also points out that there is a whole lot of work that occurs between the extraction of lithium and it ending up in a battery (here’s something amusing: cylindrical cells are sometimes referred to as “jellyrolls” and the pouch-style batteries as “chocolate bars”).

So Kochhar and Johnson established Li-Cycle, which is dedicated to recycling lithium-ion batteries in a safe manner.

(image: GM)

Kochhar says that they are able to recover approximately 95% of the important materials—like lithium, nickel and cobalt—from the batteries, which can then go back into the production of new batteries.

This past May Ultium Cells LLC, a joint venture between General Motors and LG Energy Solution, announced that it had selected Li-Cycle to recycle up to 100 percent of the material scrap from battery cell manufacturing from its battery-manufacturing facility in Ohio. This will include things like offcuts and scrap, which, Kochhar says, may be comparatively small, but given that the plant in Lordstown will have a capacity of >30 gWh, it is a non-trivial amount.

While Kochhar acknowledges that even within the next 10 years the amount of recycled critical materials from batteries will be limited—perhaps no more than 20%–there is an important need to do this.

Kochhar talks with “Autoline’s” John McElroy, Joann Muller of Axios What’s Next, and me.

And you can see it here.

GM Gets Ahead of the Curve on EV Battery Recycling

“GM’s zero-waste initiative aims to divert more than 90 percent of its manufacturing waste from landfills and incineration globally by 2025,” said Ken Morris, GM vice president of Electric and Autonomous Vehicles. This is one effort toward that end.

By Gary S. Vasilash

No one can say that General Motors and its partner LG Energy Solution aren’t being proactive.

The two companies operate a joint venture, Ultium Cells LLC. Ultium Cells will build the Ultium batteries that GM will use in its forthcoming electric vehicles (EVs).

Ultium battery for the GMC HUMMER EV Pickup. Those white slats slot into that container. (Image: GM)

GM’s current EVs—the Chevrolet Bolt EV and Bolt EUV—have lithium-ion batteries, but not Ultium batteries. That’s because the vehicles were developed pre-Ultium.

However, vehicles like the forthcoming Cadillac LYRIQ, which is to become available the first half of 2022, will have Ultium batteries on board.

Ultium Cells announced that it will be working with L-Cycle, a battery recycling company, to, well, recycle the material scrap from battery cell manufacturing.

Cobalt. Nickel. Lithium. Graphite. Manganese. Aluminum.

According to GM, 95% of the reclaimed materials can go into things like new batteries.

Li-Cycle says that the hydrometallurgical process it uses to recycle the materials is more energy efficient than other methods, like high-temperature “smelting” processes.

Which is fitting to what Ultium Cells is up to, as Thomas Gallagher, the company’s COO, said, “We strive to make more with less waste and energy expended.”

And at the very least, it undoubtedly beats the heck out of mining those materials.

The recycling process is scheduled to go on line later this year.

After all, they need to develop batteries so they can develop scrap.

Ford, HP, 3D Printing and Recycling

3D printing and recycling! In a single piece!

By Gary S. Vasilash

For some reason, 3D printing seems to be wizardly popular. This is not to say that it isn’t an exceedingly interesting way that things can be produced, even geometries that couldn’t otherwise be at all produced, but there are some processes that are simply more effective, efficient and economical, especially when it comes to things needed at automotive volumes.

Like, for example, injection molding.

Which is predicated on taking a resin that flows and injecting it into a mold, where it hardens and becomes a part.

Ford announced, “Ford and HP Collaborate to Transform 3D Waste into Auto Parts, an Industry First.”

Which it probably is.

It not like there has been such a volume of 3D printed parts being made in auto that there is a whole lot of waste that can be turned into much.

But there is some powder used in 3D printing that doesn’t become a part. There are some portions of parts (e.g., supports) that are printed then eliminated from the final part.

Ford is collecting things like that.

But there is another waste stream: SmileDirectClub, which produces more than 40,000 teeth aligners per day on its more than 60 HP 3D printers.

The waste from the various operations is being collected by a company named Lavergne, which turns them into high-quality plastic pellets.

Which are then used to injection mold fuel-line clips for the Super Duty F-250 truck by supplier ARaymond.

This is a good thing.

But somehow the tying this to the magic of 3D printing is a far reach.
